| % of Rating | 150% | 210% | 275% | 400% | 1000% |
| 200mA–5A | Min 1H | Max 2min | 400mS-10S | 150mS-3S | 20mS-150mS |
| 目錄編號 | 額定電流 | 分斷電流 | 額定電壓(AC) | 熔化熱能值 |
| 3K0200A/B | 200 mA | 35A | 125V/250V | 0.04 |
| 3K0250A/B | 250 mA | 35A | 125V/250V | 0.06 |
| 3K0315A/B | 315 mA | 35A | 125V/250V | 0.09 |
| 3K0400A/B | 400 mA | 35A | 125V/250V | 0.2 |
| 3K0500A/B | 500 mA | 35A | 125V/250V | 0.4 |
| 3K0630A/B | 630 mA | 35A | 125V/250V | 1.0 |
| 3K0800A/B | 800 mA | 35A | 125V/250V | 1.9 |
| 3K1100A/B | 1.0 A | 35A | 125V/250V | 3.3 |
| 3K1125A/B | 1.25 A | 35A | 125V/250V | 8.2 |
| 3K1160A/B | 1.6 A | 35A | 125V/250V | 17 |
| 3K1200A/B | 2.0 A | 35A | 125V/250V | 25 |
| 3K1250A/B | 2.5 A | 35A | 125V/250V | 42 |
| 3K1315A/B | 3.15 A | 35A | 125V/250V | 65 |
| 3K1400A/B | 4.0 A | 35A | 125V/250V | 94 |
| 3K1500A/B | 5.0 A | 35A | 125V/250V | 133 |
